Screen Size Class
22"
Viewable Screen Size
21.5"
Screen Mode
Full HD
Panel Technology
Vertical Alignment (VA)
Response Time
5 ms
Response Time Details
8ms GTG
5ms GTG (Fast)
Aspect Ratio
16:9
Pixel Pitch
0.2493 mm x 0.2410 mm
Horizontal Viewing Angle
178°
Vertical Viewing Angle
178°
Mount Type
Panel Mount
Backlight Technology
LED Edgelight System
HDCP Supported
Yes
Tilt Angle
-5° to 21°
Features
Eye Comfort Technology
Anti-glare
Security Lock
Narrow Bezel
Cable Lock Slot
Horizontal Frequency
30 kHz to 111 kHz - HDMI
30 kHz to 82 kHz
Vertical Frequency
50 Hz to 76 Hz
50 Hz to 100 Hz - HDMI
Stand Adjustments
Tilt
Stand Included
Yes
Glass Hardness
3H
Video
Maximum Resolution
1920 x 1080
Standard Refresh Rate
100 Hz
Colour Supported
16.7 Million Colours
Native Contrast Ratio
3,000:1
Brightness
250 cd/m2
Colour Gamut
72% NTSC (CIE 1931)
Pixel Per Inch (PPI)
102
Maximum Preset Resolution
1920 x 1080 at 100 Hz
Interfaces/Ports
Connectivity
Video port
1 HDMI port (HDCP 1.4) (Supports up to FHD 1920 x 1080 100 Hz as per specified in HDMI 1.4)
1 VGA port
Environmental Conditions
Operating Temperature Range
32°F (0°C) to 104°F (40°C)
Non-operating Temperature Range
-4°F (-20°C) to 140°F (60°C)
Operating Humidity Range
10% to 80% (Non-condensing)
Non-operating Humidity Range
5% to 90% (Non-condensing)
Maximum Operating Altitude
16400 ft (4998.72 m)
Maximum Non-operating Altitude
40000 ft (12192 m)
Power Description
Input Voltage Range
100V AC to 240V AC
Operating Power Consumption
11.70 W
Standby Power Consumption
0.3 W
Off-Mode Power Consumption
0.3 W
Frequency
50 Hz
60 Hz
Maximum Power Consumption
20.70 W
Voltage Current
1 Ah
Energy Efficiency Class
D
Physical Characteristics
VESA Mount Compatible
Yes
VESA Mount Standard
100 x 100
Height
286.48 mm
Width
492.86 mm
Depth
44.90 mm
Height with Stand
395.75 mm
Width with Stand
492.86 mm
Depth with Stand
211.80 mm
Compressed Height with Stand
395.75 mm
Bezel Width (Top)
7.11 mm
Bezel Width (Bottom)
18.54 mm
Bezel Width (Left)
7.11 mm
Bezel Width (Right)
7.11 mm
Weight (Approximate)
2.23 kg
Stand Height
181.60 mm
Stand Width
219.90 mm
Stand Depth
211.80 mm
Weight with Stand (Approximate)
2.96 kg
Miscellaneous
Package Contents
Monitor
Stand
Cleaning Cloth
Drivers and Documentation Media
Quick Start Guide
Safety Information
Factory Calibration Report
Energy Star
Yes
TAA Compliant
Yes
TCO Certified
Yes
Cable Type Included
Power Cable
1 x HDMI Cable - 1.8 m
Energy Efficiency Certification
ENERGY STAR 8.0
Energy Efficiency Compliance
Energy-related Products Directive Lot 5 (ErP Lot 5)
Minimum Energy Performance Standards (MEPS)
Energy Efficiency Compliance
Minimum Energy Performance Standards (MEPS)
Environmental Compliance
Restriction of Hazardous Substances (RoHS)
